Specification
Basic Information | ||
Supported CPU | AMD AM4 Socket for AMD Ryzen 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors | |
Chipset | AMD B550 Chipset | |
BIOS | 256 Mb Flash ROM, UEFI AMI BIOS | |
Form Factor | mATX Form Factor 9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm ) | |
Expansion Slots | ||
PCI | AMD Ryzen 5000 Series/ 3000 Series Desktop Processors AMD Ryzen 5000 G-Series/ 4000 G-Series Desktop Processors AMD B550 Chipset | |
M.2 Socket | 2 x M.2 slots | |
Memory | ||
Type | Dual Channel Memory Architecture | |
Slots | 4 x DDR4 memory slots | |
Supported Memory | 4866(OC)/ 4800(OC)/ 4600(OC)/ 4466(OC)/ 4400(OC)/ 4333(OC)/ 4266(OC)/ 4200(OC)/ 4133(OC)/ 4000(OC)/ 3866(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz, Un-buffered Memory* | |
Maximum Memory | 128GB | |
Graphics | ||
Graphics | 1 x DisplayPort 1.2 1 x D-Sub 1 x HDMI 2.1 (4K@60Hz) | |
Connector & Ports | ||
HDMI | 1 x HDMI 2.1(4K@60HZ) | |
Display Port (s) | 1 x DisplayPort 1.2 | |
D-Sub (s) | 1 x D-Sub | |
USB (s) | Rear USB (Total 6 ports) Front USB (Total 7 ports) | |
LAN Port (s) | 1 x Realtek 1Gb Ethernet | |
Supported Storage | Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen 5000 Series/ 3000 Series Desktop Processors AMD Ryzen 4000 G-Series Desktop Processors AMD B550 Chipset 4 x SATA 6Gb/s ports | |
Audio | Realtek ALC887/897 7.1 Surround Sound High Definition Audio CODEC* Audio Features * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. | |
Internal I/O Ports | Fan and Cooling related Power related Storage related USB Miscellaneous | |
TPM (Trusted Platform Module ) | 1 x SPI TPM header (14-1pin) | |
Others | ||
Special Features | ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - AI Noise Cancelling Microphone AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 2+ - EZ update TUF GAMING CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools DTS Custom for GAMING Headsets Norton Anti-virus software (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS TUF PROTECTION - ASUS DIGI+ VRM (Digital power design with Dr. MOS) - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - TUF LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - ASUS Q-Slot ASUS Thermal Solution - Aluminum M.2 heatsink ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - Procool AURA Sync - Standard RGB headers - Addressable Gen 2 RGB header | |
Warranty Information | ||
Manufacturing Warranty | 3 Years |
Brief Description
- AMD AM4 Socket: Ready for Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
- Enhanced Power Solution: Alloy Chokes, military-grade TUF components, and DIGI+ VRM for maximum durability
- Comprehensive Cooling: Large VRM heatsink, M.2 heatsink, PCH fanless heatsink, hybrid fan headers, and Fan Xpert 2+ utility
- Ultrafast Connectivity: Dual M.2, PCIe 4.0, USB 3.2 Gen 2 Type-A, and front USB 3.2 Gen 1 Type-C® support
- Made for Online Gaming: 1 Gb Ethernet, TUF LANGuard and Turbo LAN technology
- Aura Sync RGB Lighting: Onboard addressable Gen 2 headers and RGB headers for RGB LED strips, easily synced with Aura Sync-capable hardware
DURABLE. STABLE. RELIABLE.
TUF GAMING B550M-E distills essential elements of the latest AMD platform and combines them with game-ready features and proven durability. Engineered with military-grade components, an upgraded power solution and a comprehensive set of cooling options, this motherboard delivers rock-solid performance with unwavering gaming stability.
When you build with a TUF Gaming motherboard, you also benefit from the TUF Gaming Alliance — an ASUS collaboration with trusted industry partners that ensures easier building, best compatibility, and complementary aesthetics from components to case.
EASY PC DIY
TUF Gaming motherboards are designed to be easy to set up and configure just the way you want — even for first-time builders. The TUF Gaming Alliance ecosystem makes selecting compatible parts easy, while Armoury Crate software offers full control of system settings via a single dashboard. TUF Gaming motherboards give you everything you need to build your dream gaming rig without adding complexity.
Build with confidence
TUF Gaming Alliance is a collaboration between ASUS and trusted PC-component brands to ensure compatibility with a wide range of parts, such as PC cases, power supplies, CPU coolers, memory kits and more. With more partnerships and components being added regularly, the TUF Gaming Alliance will continue to grow even stronger.
What is the price of the Asus Tuf Gaming B550ME AMD B550 (Ryzen AM4) micro ATX gaming Motherboard in Bangladesh?
The latest Asus Tuf Gaming B550ME AMD B550 (Ryzen AM4) micro ATX gaming Motherboard in Bangladesh is 14,500৳. You can buy the Gigabyte 410MH V3 Motherboard at the best price from our website or visit our showroom.
Where to buy Asus Tuf Gaming B550ME AMD B550 (Ryzen AM4) micro ATX gaming Motherboard in Bangladesh?
You can buy Asus Tuf Gaming B550ME AMD B550 (Ryzen AM4) micro ATX gaming Motherboard from our online shop or in person at our showroom. Shop with confidence and take advantage when you buy from our online store.
